| 插芯 | ||
| 接插件针数 | Number Of Contacts | 8 |
| 依据EN 61 984的电气数据 |
Electrical Data Acc. To EN 61 984
|
|
| －额定电流 | －Rated Current1 |
A |
| －额定电压 | －Rated Voltage | 50V |
| －额定脉冲电压 | －Rated Impulse Voltage | 0.8KV |
| －污染程度 | －Pollution Degree | 3 |
|
依据UL的额定电压
|
Rated voltage acc. to UL
|
30V
|
|
传输特性
|
Transmission features
|
Category 6 /Class E
up to 500 MHz; acc. to
ISO/IEC 11 801:2002
and EN 50 173-1
|
|
传输速率
|
Transmission rate
|
10/100/1000 Mbit/s
|
| 绝缘电阻 | Insulation Resistance | ≥1010Ω |
| 材料 | Material | 聚碳酸酯 Polycarbonate |
| 工作温度范围 | Limiting Temperatures | -40℃...+85℃ |
| 依据UL 94阻燃等级 | Flammability Acc. To UL94 | V0 |
| 可拔插次数 | MecHEnical Working Life-mating Cycles | ≥500 |
